XS12CA2JCR Nidec 1/2 Hp 1800 RPM 56C Frame 60 Hz 115/208-230V TEFC Cap Start Hazardous Duty Motor

XS12CA2JCR Nidec 1/2 Hp 1800 RPM 56C Frame 60 Hz 115/208-230V TEFC Cap Start Hazardous Duty Motor - Image 2

XS12CA2JCR Nidec 1/2 Hp 1800 RPM 56C Frame 60 Hz 115/208-230V TEFC Cap Start Hazardous Duty Motor

Original price was: $343.00.Current price is: $99.99.

SKU: ZWXLY 1698659411 Category: Electric Motors Tag: Nidec

Discover a world of quality products.
Secure Shopping Starts with Safe Payments
Uncompromising quality, every time.
Free 1 year warranty period

Description
Reviews (0)

1/2 hp 1800 RPM, 9.8/4.9-4.9 amps 115/208-230 Volts 60 Hz Capacitor Start Motor
NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8″ Diameter x 1 7/8″
Service Factor: 1.0, Overload protection = Auto
C-Face Mount, Ball Bearings, Class B Insulation, Reversible
1 Year Manufacture Warranty

General purpose Division 1 hazardous location motor for class 1 group CD, class 2 group EFG. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CH63ABK1031015B
