JMP0056 TECO Westinghouse 5 Hp 1200 RPM 213/215JM Cast Iron 230/460V TEFC Close-Coupled 3-Phase Motor

JMP0056 TECO Westinghouse 5 Hp 1200 RPM 213/215JM Cast Iron 230/460V TEFC Close-Coupled 3-Phase Motor - Image 2

JMP0056 TECO Westinghouse 5 Hp 1200 RPM 213/215JM Cast Iron 230/460V TEFC Close-Coupled 3-Phase Motor -Electric Motor Warehouse Store jmp0056 line 04863.1692035027

JMP0056 TECO Westinghouse 5 Hp 1200 RPM 213/215JM Cast Iron 230/460V TEFC Close-Coupled 3-Phase Motor

Original price was: $309.00.Current price is: $98.99.

SKU: ZWXLY 1698662132 Categories: Electric Motors, TECO-Westinghouse Electric Motors Tag: TECO WESTINGHOUSE

Discover a world of quality products.
Secure Shopping Starts with Safe Payments
Uncompromising quality, every time.
Free 1 year warranty period

Description
Reviews (0)

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

5 hp 1200 RPM, 12.48/6.24 amps 230/460 Volts 60Hz. Three Phase
NEMA 213/215JM Frame, Special Shaft
Cast Iron Frame, Enclosure: Totally Enclosed Fan Cooled (IP54)
Service Factor: 1.15, Thermal Overload Protection: None
Rigid Base, Reversible, Ball Bearings, Class F Insulation
Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
Inverter Duty Speed Range: 10:1 Variable Torque, 5:1 Constant Torque
Motors are U.L. Recognized, CSA Approved and CE Marked
1 Year Manufacture Warranty

Applications: Fans & Blowers, Pumps, Crushers, Compressors, Mixers, Conveyors
