Sale!

119435.00 Leeson 3 Hp 3600 RPM 230/460V 56C Frame Explosion-Proof (No Base) 3-Phase TEFC Motor

119435.00 Leeson 3 Hp 3600 RPM 230/460V 56C Frame Explosion-Proof (No Base) 3-Phase TEFC Motor - Image 2

119435.00 Leeson 3 Hp 3600 RPM 230/460V 56C Frame Explosion-Proof (No Base) 3-Phase TEFC Motor - Image 3

119435.00 Leeson 3 Hp 3600 RPM 230/460V 56C Frame Explosion-Proof (No Base) 3-Phase TEFC Motor

Original price was: $331.00.Current price is: $99.99.

SKU: ZWXLY 1698655630 Categories: Electric Motors, Leeson/Marathon Electric Motors Tag: Leeson

Discover a world of quality products.
Secure Shopping Starts with Safe Payments
Uncompromising quality, every time.
Free 1 year warranty period

Description
Reviews (0)

3 hp 3600 RPM, 8.2-7.6/2.5 amps 208-230/460 Volts 60 Hz. 3-Phase Motor
NEMA 56C Frame Keyed Shaft 5/8″ Diameter x 1 7/8″
Service Factor: 1.0, Overload Protection = Auto
No Base, Reversible, Ball Bearings – Class B Insulation
1 Year Manufacture Warranty

Explosion-Proof motor for use in hazardous environments with a C-face mount. DIV 1 EXP PROOF CL I GR CD CL II GR FG T3C. Bolt holes are 3 3/4″ on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. 119435.00
